Effective pressure relief and relaxed positioning for long sitting periods thanks to electrical adjustment ranges
Various seating systems according to individual needs
With innovative LiNX control system: Easy to understand, simple to operate and offers intuitive & individual configuration
Options
Rear-view mirror right
Rear-view mirror left
Rear marking plate
Compatible parts
Innovative LiNX control from Dynamic Controls
Castor wheels with aluminium rim
Standard side panel
Total width
600 - 750
Seat width 1,2,3
380 - 600
Seat depth 2,3
400 - 530
Back rest height 2,3
500
Shank lenght 2,3
280 - 430
Arm support height 2,3
240 - 350
Front seat height 2,3
440 / 480 / 510
Length with footrests
1,080
Length without footrests
840
Width ready to move (without armrests)
630
Height without headrest
930 - 1,130
Transport dim. length
840
Transport dim. height min.
560 - 660
Transport dim. width
630
Front wheel size
230 x 70 (9")
Rear wheel size
356 x 75 (14")
Max. obstacle height
60
Turning radius
mind. 840
Min. transport weight empty basic version 4
94
User weight max.
130
Permissible total weight incl. options
280
Max. additional load
10
Speeds km/h
6 / 10
Motor power W
2 x 180 / 2 x 300
Permitted gradient 43 Ah (5h), 50 Ah (20h) max. 6
max. 30 km
Permitted nominal uphill / downhill gradient
8.5° / 15 %
Type of steering
indirect
Electric tilt-in-space
-4° to 24°
Mechanical tilt-in-space
0° - 10°
Back angle electric
-10° to 50°
Back angle mechanical
-10° to 30°
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
1) see category Seat width 01 2) seating systems belt / Netti Sit / Ride Forward 3) seat angle 0° 4) Without legrests and without armrests 6) see category 00 chassis/motor 7) The adjustment range may deviate by max. +/-3° depending on SH and castor wheel size.
