Seat width 530 - 700 Seat depth 430 - 600 Back rest height 530 - 570 Shank lenght 370 - 510 Arm support height 170 - 280 Front seat height (with / without 460 - 560 / 530 - 630 Length with footrests 1,150 Length without footrests 850 Width ready to go 670 Height without headrest 1,020 - 1,150 Transport dim. width 710 - 760 Transport dim. length 850 Transport dim. height min. 650 Front wheel size 260 x 70 (10“) Rear wheel size 350 x 75 (14“) Max. obstacle height max. 60 Turning radius 950 Reichweite mit Batterie 63 Ah (5h), 73 Ah (20h) max. 6) 30 - 35 Empty transport weight min. 130 Client weight max. 160 - 200 Permitted overall weight 340 Additional loading max. 10 Driving speeds 6 /10 Motor performance 2 x 300 / 2 x 350 Driving range max. 35 Permitted gradient 13 % Type of steering indirect Electric lift 300 Electric tilt-in-space 0° - +18° Mechanical tilt-in-space 0° - +10° Back angle electric -10° - +50° Back angle mechanical -10° - +30°
Dimensions in mm, Weights in kg, Speed in km/h, Tolerance ± 10 mm
